Description
General
- 6 years & 3 months structural warranty
- 12-month material warranty
- Any additional upgrades not included
Structure / Carcass
- Heavy-duty external structural steel framing
- Heavy-gauge steel floor joists & bearers
- Heavy-gauge corner posts for bracing and increased load capacity
Roofing
- Durable corrugated Corten steel welded roofing with four layers of anti-corrosion paint
- Closed-cell polyurethane insulation (R5.1) applied to interior ceilings
Windows & Doors
- Double-glazed tempered glass (5 mm) in aluminium-framed windows and sliding doors
- Keyed locks fitted to all external doors
Internal Fit Out
- 2400 mm nominal internal ceiling height (measured overall to framing members)
- Lightweight steel framing to all internal walls
- Compressed fibre cement flooring, glued and screw-fixed to steel floor joists
- 10 mm plasterboard-lined walls throughout with shadowline profile at ceiling and wall junction (excluding wet areas)
- Painted architraves and skirting throughout, including jamb sets for door openings (depending on design, excluding wet areas)
- Painted flush-panel internal doors
- Architectural Lever Series internal door furniture with privacy locks to bathroom and WC provisions
- All internal plumbing
- Polyethylene pressure piping is fully connected beneath the modular building
Electrical
- The electrical main supply lead is folded underneath the modular building for external connection
- Internal switchboard
- One recessed LED light fitting per internal room
- One external LED light fitting
- One double general power outlet per room)
- One phone point to the living area (depending on design)
- One data point for the living area (depending on design)
- One TV point to the living area (depending on design)
- Smoke alarms are photoelectric type—one per bedroom and one in the main central area, all connected to mains electricity with battery backup and positioned in flow areas
- External meter box not included
Kitchen
- Custom-built kitchen cabinetry with overhead cupboards (as per design)
- Custom-built square-edged reconstituted quartz stone benchtop (depending on desig
- Gloss 2-pack finish or melamine laminate to kitchen cupboard fronts, including metal cabinet handles (depending on design)
- Timber veneer finish to kitchen cupboard fronts with built-in concealed cabinet handles (depending on design)
- Four-drawer cutlery unit with Blum soft-closing drawer slides
- 600 mm high ceramic tiled kitchen splashback (depending on design)
- Provision for dishwasher, including cold water connection, electrical, and waste disposal
- Builder’s range stainless steel kitchen sink (number of bowls depending on design)
- Builder’s range kitchen mixer — one per kitchen sink
Bathroom
- Custom-built bathroom cabinetry
- Toughened glass blade shower screens or shower curtain (depending on design)
- Full-height ceramic tiles to the shower recess; remaining bathroom walls tiled to half wall height
- Wall-mounted vanity cabinet with vitreous china single vanity bowl
- Builder’s range vanity basin mixer — one per vanity basin
- Builder’s range wall mixer — one per shower
- Builder’s range shower rose on rail combination — one per shower
- Builder’s range ¼ turn cistern cocks — one per WC
- Builder’s range deluxe 3-star WELS-rated wall-faced vitreous china toilet suite with soft-closing seat and lid
- Builder’s range towel rail — one per bathroom
- Builder’s range toilet roll holder — one per WC
- Builder’s range wall-mounted soap holder — one per shower recess
- Fibre cement-lined walls to all bathrooms
Laundry(Selected Floor plan）
- Custom-built laundry cabinetry
- Laundry cabinet with stainless steel sink and reconstituted quartz stone benchtop (depending on design)
- Builder’s range laundry mixer — one per laundry tub
- Builder’s range ¼ turn washing machine cocks — one per washing machine
